Wabco 4324210090 air dryer with a desiccant cartridge, a 12 V unit with a Delphi Metri-Pack 280 heating connection. It sits in the compressed air supply of a truck's air brake system and strips moisture and contaminants out of the air before it reaches the brake and accessory circuits. The desiccant cartridge absorbs the water vapor left after the coarse dirt has been filtered out, and it is the service item: when the desiccant is saturated the cartridge is replaced rather than the whole dryer. Cut-out pressure runs 114.58 to 130.53 psi, with a maximum operating pressure of 188.5 psi. A genuine Wabco part from Pro Gear and Transmission.
Features
Desiccant cartridge air dryer
12 V with Delphi Metri-Pack 280 heating connection
Cut-out pressure 114.58 to 130.53 psi
Max. operating pressure 188.5 psi
Temperature range -40°C to +65°C
Size 286 x 146 x 149 mm
Tech Specs
- Calculated Volume (dm³)6.2216
- Cartridge type Desiccant Cartridge
- Cut-out pressure 114.58 to 130.53 psi
- Exhaust No (432 407 012 0 retrofittable)
- Heater894 260 046 2
- Heating connection DELPHI METRI PACK 280
- Max. operating pressure 188.5 psi
- Opening pressure 188.55 psi
- Port thread 1 1/2" - 14 NPTF
- Port thread 21 1/2" - 14 NPTF
- Port thread 22 1/4" - 18 NPTF
- Port thread 4/2 31/4" - 18 NPTF
- Silencer No (432 407 012 0 retrofittable)
- Technical specification OE specification
- Temperature range -40°C to +65°C
- Unloader No
- Voltage 12 V
- Size (mm x mm x mm)286 x 146 x 149
