Genuine Wabco Brake Chamber P/N: 4231070150 or 423-107-015-0, for help on parts, availability or questions, call us, we will gladly help.
Tech Specs
- Brand WABCO
- Part type Premium original quality
- Product category Device
- Bolt lengths 1.50 in
- Bolt threads 5/8"
- Clevis pin 0.51 in
- Distance between bolts 4.75 in
- Max. operating pressure 116.0 psi
- Output force 2248.09 lbf
- Output force M2248.09 lbf
- Port threads 3/8" - 18 NPTF
- Push-rod length 2.25 in
- Push-rod thread 3/8"
- Return-spring force 29.23 lbf
- Stroke 2.99 in
- Technical specification OE specification
- Temperature rang e-40°C to +80°C
- Total lenght 4.88 in
- Type30
- Type of operation Cam
- Version Without boot
- Yoke With
