Wabco Brake Chamber P/N: 4231049000. Genuine Wabco OEM brake parts, brake calipers, brake chambers, brake dust shields, brake shoes, brake valves, and more. Genuine Wabco parts are just a click or call away.
Tech Specs
- Brand WABCO
- Part type Premium original quality
- Product category Device
- Bolt lengths 1.00 in
- Bolt threads M12 x 1.5
- Calculated Volume (dm³)8.805
- Clamp Band 6.54 in
- Clamp band position -45°
- Distance between bolts 3 in
- Max. operating pressure 123.28 psi
- Operating pressure 123.3 psi
- Output force 1461.26 lbf
- Output force M1461.26 lbf
- Port (side)M16 x 1.5 JED-152
- Port (top)M16 x 1.5 JED-152
- Port angle 180°
- Port threads M16 x 1.5 JED-152
- Push-rod length 7.32 in
- Push-rod thread M16 x 1.5
- Return-spring force 22.48 lbf
- Stroke 2.95 in
- Technical specification OE specification
- Temperature range -40°F to +176°F
- Thread length 8.94 in
- Total lenght 5.04 in
- Type16
- Type of operation Cam
- Version Without boot
- Yoke Without
- Size (mm x mm x mm)316 x 172 x 162
