The Wabco 925-48-10160 (also listed as 9254810160) is a Type 24/30 IBV air disc brake chamber built to OEM specification. Designed for disc brake operation, it delivers a 2.56 in. stroke and handles a maximum operating pressure of 147.94/123.28 psi, with a release pressure of 53.95 lbf return-spring force and a 95.73 psi release threshold. Total length is 11.30 in., overall dimensions are 403 x 206 x 206 mm, and the push-rod uses a Ball R8 thread. Bolt threads are M16 x 1.5 with a 4.75 in. bolt spacing. The port thread is 1-3/8"-18 NPTF. Rated for -40°C to +80°C operating temperature. Cross-references include 82359254810160 and TDA9254810160. Available from Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
Type 24/30 IBV disc brake chamber, built to OEM specification
Total length 11.30 in. (403 x 206 x 206 mm overall dimensions)
Stroke: 2.56 in.
Max. operating pressure: 147.94 / 123.28 psi; release pressure: 95.73 psi
Bolt threads M16 x 1.5, bolt spacing 4.75 in., bolt length 1.69 in.
Port thread 1-3/8"-18 NPTF; push-rod thread Ball R8; temperature range -40°C to +80°C
Tech Specs
- Brand: Wabco
- Part Number: 925-48-10160 or 9254810160
- Type: 24/30 IBV
- Type of Operation: Disc Brake
- Technical Specification: OE Specification
- Total Length: 11.30 in.
- Dimensions: 403 x 206 x 206 mm
- Stroke: 2.56 / 2.56 in.
- Max. Operating Pressure: 147.94 / 123.28 psi
- Release Pressure: 95.73 psi
- Return-Spring Force: 53.95 lbf
- Push-Rod Length: 0.59 in.
- Push-Rod Thread: Ball R8
- Port Thread: 1-3/8"-18 NPTF
- Bolt Threads: M16 x 1.5
- Bolt Length: 1.69 in.
- Distance Between Bolts: 4.75 in.
- Temperature Range: -40°C to +80°C
