The Wabco air brake chamber, part number 4230580020 or 423-058-002-0, is a Type 36 service chamber built to OE specification. It delivers a maximum output force of 3372.14 lbf at a rated stroke of 2.95 inches and is rated for a maximum operating pressure of 145.0 psi. The con-rod length measures 1.81 in, with bolt hole spacing of 3.25 in and 4.92 in. Mounting is provided by two M12 x 1.5 studs and three M10 studs. Port thread is M16 x 1.5 and push-rod thread is R 0.3 in. The chamber is supplied without a console mounting bracket and operates across a temperature range of -40 C to +80 C. Call us to confirm proper fit for your application.
Features
Type 36 service brake chamber built to OE specification
Stroke: 2.95 in with output force of 3372.14 lbf
Max. operating pressure: 145.0 psi
Mounting: 2 x M12 x 1.5 and 3 x M10 studs, distance between holes 3.25/4.92 in
Port thread M16 x 1.5, push-rod thread R 0.3 in
Operating temperature range: -40 C to +80 C, supplied without console mounting bracket
Tech Specs
- Brand: Wabco
- Type: 36
- Technical specification: OE specification
- Stroke: 2.95 in
- Con-rod length: 1.81 in
- Output force: 3372.14 lbf
- Max. operating pressure: 145.0 psi
- Distance between holes: 3.25/4.92 in
- Mounting: 2 x M12 x 1.5 / 3 x M10
- Port thread: M16 x 1.5
- Push-rod thread: R 0.3 in
- Temperature range: -40 C to +80 C
- Version: Without console mounting
- Size: 270 x 270 x 220 mm
