The Wabco Quick Release Valve, part number 973-500-000-0 or 9735000000, is a genuine OE-specification air system valve built with an integrated double check valve. All three port threads are M22 x 1.5, and the exhaust is also M22 x 1.5. Maximum operating pressure is 174 psi, and the unit is rated for a temperature range of -40°C to +80°C. Nominal diameter is 14.0 mm, and overall dimensions are 87 x 71.5 x 65 mm. The two mounting holes are spaced 1.5 in. apart on 9.5 mm diameter bores. Sold by Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
Genuine OE-specification Wabco air system quick release valve
Includes integrated double check valve
All three ports threaded M22 x 1.5; exhaust also M22 x 1.5
Maximum operating pressure: 174 psi
Operating temperature range: -40°C to +80°C
Overall size: 87 x 71.5 x 65 mm; mounting bolt spacing 1.5 in. on 9.5 mm bores
Tech Specs
- Brand: WABCO
- OE Specification: Yes
- With Double Check Valve: Yes
- Port Thread 1: M22 x 1.5
- Port Thread 2: M22 x 1.5
- Port Thread 3: M22 x 1.5
- Exhaust: M22 x 1.5
- Nominal Diameter: 14.0 mm
- Max. Operating Pressure: 174 psi
- Temperature Range: -40°C to +80°C
- Size (mm): 87 x 71.5 x 65
- Distance Between Bolts: 1.5 in.
- Mounting: 2x 9.5 mm diameter bores
