Genuine Wabco Quick Release Valve P/N: 9735000510, in box ready to ship! Do not hesitate to ask us any questions.
Tech Specs
- Brand WABCO
- Part type Premium original quality
- Product category Device
- Calculated Volume (dm³)0.56232
- Comments With Integrated double cut-off valve
- Distance between bolts 1.5 in
- Exhaust M22 x 1.5
- Max. operating pressure 174 psi
- Mounting 2x Ø 9.5 mm
- Port thread 11M22 x 1.5
- Port thread 12M22 x 1.5
- Port thread 24x M16 x 1.5
- Port thread 21M16 x 1.5
- Port thread 22M16 x 1.5
- Port thread 23M16 x 1.5
- Port thread 24M16 x 1.5
- Port thread 3M22 x 1.5
- Technical specification OE specification
- Temperature range -40°C to +80°C
- Size (mm x mm x mm)90 x 88 x 71
