The Wabco 4410329000 is a Type S+ axial speed sensor built to OE specification for heavy-duty truck brake systems. It mounts via a bushing and connects through a power socket electrical connection. The sensor body measures 164 mm x 35 mm x 189 mm with a 0.63 in. diameter sensing tip and a 2000 mm cable length. Dual protection ratings of IP 6K8 and IP 6K9K (per ISO 20653) confirm resistance to high-pressure washdown and dust ingress. The operating temperature range runs from -40C to +80C, covering cold-start and sustained highway heat. Call us to confirm proper fit for your specific axle and brake configuration.
This part is now supplied as a kit.
This product has been superseded and is no longer available. If ordered, you will receive 4410329682.
Features
Type S+ axial version speed sensor, OE specification
Bushing mounting with power socket electrical connection
0.63 in. diameter sensing tip; overall body 164 x 35 x 189 mm
2000 mm (approx. 78.7 in.) cable length
Dual protection class IP 6K8 and IP 6K9K per ISO 20653 - dust-tight and high-pressure wash resistant
Operating temperature range: -40C to +80C
Tech Specs
- Brand: WABCO
- Part Number: 4410329000
- Type: S+ Axial Speed Sensor
- Mounting: Bushing
- Electrical Connection: Power Socket
- Diameter: 0.63 in.
- Cable Length: 2000 mm
- Size (L x W x H): 164 mm x 35 mm x 189 mm
- Protection Class: IP 6K8, IP 6K9K (ISO 20653)
- Operating Temperature Range: -40C to +80C
- Specification: OE specification
