Wabco Valve Assembly brake parts P/N: 4721708770, ready to ship worldwide! Call us with any questions.
Tech Specs
- Brand WABCO
- Part type Premium original quality
- Product category Device
- Calculated Volume (dm³)0.28111
- Electrical connection DIN 72 585 A1-2.1-Sn/K1
- Exhaust 4.0 mm
- Max. operating pressure 147.94 psi
- Multi Nominal diameter (From Port 1 to x)0.16 in
- Port thread 11/4" - 18 NPTF
- Port thread 21/4" - 18 NPTF
- Port thread 31/4" - 18 NPTF
- Protection class IP 6K9K, IP 6K7
- Rated current 1410 mA
- Technical specification OE specification
- Temperature range -40°C to +80°C
- Type Normally Closed
- Voltage 12 V
- Size (mm x mm x mm)39 x 106 x 68
