Wabco Valve-Solenoid brake parts P/N: 4728800640, in box ready to ship today! Do not hesitate to ask us any questions.
Non returnable item
Tech Specs
- Brand WABCO
- Part type Premium original quality
- Product category Device
- Calculated Volume (dm³)3.8327
- Electrical connection Bayonet DIN 72585-A1-4.1-Sn/K2, Bayonet DIN 72585-A1-3.6-Sn/K2
- Max. operating pressure 290.1 psi
- Mounting 2 x Ø 9 mm
- Multi Nominal diameter (From Port 1 to x)0.39 / 0.28 / 0.02 in
- Port thread 11M22 x 1.5 JED - 388
- Port thread 21M22 x 1.5 JED - 388
- Port thread 22M22 x 1.5 JED - 388
- Port thread 23M22 x 1.5 JED - 388
- Port thread 3 Silencer 432 407 060 0
- Protection class IP 6K9K
- Rated current 320 mA
- Technical specification OE specification
- Temperature range -40°C to +80°C
- Voltage 24 V
- Size (mm x mm x mm)205 x 164 x 114
