The Meritor E8968-L or E8968L is a left-hand threaded, Grade 8 wheel-end stud sold in a 5-pack unit. Cataloged under the Euclid Brake and Wheel End line, it carries a 3/4"-16 UNF-2A thread, a body diameter of 0.785 in., and an overall length from under the head of 3-3/16 in. The serrated shank measures 0.820 in. in diameter across a 0.50 in. serration length, locking firmly into the hub flange. Thread length is 1.92 in. and body length is 0.97 in. The round head is 1.25 in. in diameter and 0.31 in. thick. Call us to confirm proper fit for your axle and hub configuration.
Interchanges:
- Automann 2016050L
- BWP M3615
- Conmet 10001334
- Dayton Parts Batco 131135L
- Flagg W755
- Gunite W980L
- Sirco Brake 419
- World Truck 1681009L
This unit is sold in packs of 5.
Features
Left-hand (LH) thread direction, 3/4"-16 UNF-2A thread form
Grade 8 construction, round headed stud
Body diameter 0.785 in., serration diameter 0.820 in.
Length from under head: 3-3/16 in.; thread length 1.92 in.; body length 0.97 in.
Serrated shank for secure hub engagement, serration length 0.50 in.
Tech Specs
- Thread: 3/4"-16 UNF-2A
- Thread Direction: Left Hand (LH)
- Grade: 8
- Head Style: Round
- Head Diameter: 1.25 in.
- Head Thickness: 0.31 in.
- Body Diameter: 0.785 in.
- Serration Diameter: 0.820 in.
- Serration Length: 0.50 in.
- Body Length: 0.97 in.
- Thread Length: 1.92 in.
- Length from Under Head: 3-3/16 in.
- Type: Headed, Serrated
- Unit Pack: 5
- VMRS Code: 018-003-009
