Meritor part number 09-001555 or 09001555 is a right hand, headed wheel end stud sold in a 5-pack. This Grade 8 stud features a 3/4"-16 UNF thread with 16 threads per inch and a thread length of 1.16 in. The overall length from under the head measures 2-3/8 in., with a stepped body diameter of 0.901 in. transitioning to 0.890 in. and a body length of 0.94 in. The round head measures 1.31 in. in diameter and 0.31 in. thick. A serrated shank section 0.44 in. long and 0.939 in. in diameter locks the stud firmly in the hub. Call us to confirm proper fit for your application.
Interchanges:
- 09001555RI
- 823509001555
- TDA09001555
- Automann 2016233R
- Euclid E-11665-R
This unit is sold in packs of 5.
Features
Grade 8 right hand (RH) headed wheel stud
3/4"-16 UNF thread, 1.16 in. thread length, 16 threads per inch
2-3/8 in. length from under head; 0.94 in. body length
Stepped body diameter: 0.901 in. / 0.890 in.
Serrated shank: 0.939 in. diameter x 0.44 in. long for secure hub retention
Tech Specs
- Thread: 3/4"-16 UNF (Right Hand)
- Threads per Inch: 16
- Thread Length: 1.16 in.
- Thread Diameter: 0.75 in.
- Length from Under Head: 2-3/8 in.
- Body Length: 0.94 in.
- Body Diameter: 0.901 in. / 0.890 in. (Stepped)
- Serration Length: 0.44 in.
- Serration Diameter: 0.939 in.
- Head Style: Round
- Head Diameter: 1.31 in.
- Head Thickness: 0.31 in.
- Grade: 8
- Type: Headed
- VMRS Code: 018-003-009
