The Chelsea 288 Series Power Take-Off (part 288GDFJW-M5RK or 288GDFJWM5RK) is a heavy-duty 10-bolt constant mesh PTO built on the 281 Series platform. The 288 Series delivers a continuous duty torque rating of up to 390 lb-ft and offers nine speed ratios covering both low and high ranges. Ductile iron bearing caps are 117% stronger than gray iron, and an O-ring sealing configuration between the housing and bearing cap reduces vibrational effects and improves clamp load. The standard output shaft is a round shaft with a 1-inch, 1/4-inch key configuration. A positive-stop feature on driveline outputs eliminates oil seal damage from shaft couplings. The optional Wet Spline lubrication system extends pump shaft life by 7 to 10 times. Call us to confirm proper fit for your application.
Features
10-Bolt mounting, constant mesh design with cast iron housing
Continuous duty torque rating up to 390 lb-ft
Ductile iron bearing caps rated 117% stronger than gray iron
O-ring seal between housing and bearing cap reduces vibration effects and improves clamp load
Positive-stop output shaft eliminates oil seal damage from driveline couplings
Wet Spline lubrication option extends pump shaft life 7 to 10 times; hose included
Tech Specs
- Mounting Type: 10-Bolt
- Shift Type: Constant Mesh
- Output Shaft: Round shaft, 1 in. with 1/4 in. key
- Continuous Duty Torque: Up to 390 lb-ft
- Speed Ratios: Nine ratios including low and high speeds
- Lubrication: Pressure lube or Wet Spline (application dependent)
- Housing: Cast iron
- Bearing Caps: Ductile iron
- Replaces: Chelsea 287 Series
