The Chelsea 272 Series Power Take-Off Assembly, part number 272GAHVP-K3XD or 272GAHVPK3XD, is a 6-bolt hot-shift PTO built for medium-duty applications including aerial, construction equipment, towing and recovery, and water trucks. It features a 1-1/4" round output shaft with a 5/16" key and shifts pneumatically or via PowerShift (pneumatic/hydraulic). Continuous torque capability reaches 300 lb-ft (407 Nm), with intermittent torque rated at 201-300 lb-ft (401-500 Nm). Shaft power output is 57 HP (43 kW) at 1,000 RPM. The 272 Series consolidates several prior Chelsea medium-duty PTO lines into one versatile platform, offering rotatable flanges, an integral air control valve, and optional wet-spline and Smart-Start features. Compatible with Allison, Eaton/Fuller, Ford, Aisin, Volvo/Mack, and RAM transmissions, among others. Call us to confirm proper fit for your application.
Features
6-bolt mounting with rotatable flanges for flexible installation
Pneumatic or PowerShift (pneumatic/hydraulic) shift operation with integral air control valve
1-1/4" round output shaft with 5/16" key
Continuous torque rating up to 300 lb-ft (407 Nm); intermittent torque 201-300 lb-ft (401-500 Nm)
Shaft power output: 57 HP (43 kW) at 1,000 RPM
Optional wet-spline design and Smart-Start feature for high-torque start-up conditions
Tech Specs
- Mounting Type: 6-Bolt
- Shift Type: Pneumatic / PowerShift (Pneumatic/Hydraulic)
- Output Shaft Type: 1-1/4" Round with 5/16" Key
- Intermittent Torque: 201-300 lb-ft (401-500 Nm)
- Continuous Torque: 300 lb-ft (407 Nm) - check application pages for actual torque ratings
- Output Power: 56+ HP (41-50 kW)
- Shaft Power at 500 RPM: 29 HP (21 kW)
- Shaft Power at 1,000 RPM: 57 HP (43 kW)
- Compatible Transmissions: Allison, Eaton/Fuller, Ford, Aisin, Volvo/Mack, RAM, and other makes
- Applications: Aerial, Construction Equipment, Towing and Recovery, Water Trucks
