Chelsea PTO Assembly P/N: 281GBKVP-B8XD or 281GBKVPB8XD

281GBKVP-B8XD Chelsea PTO Assembly

Chelsea

Listing Price: $4,220.33
Sale Price: $3,089.28

This item qualifies for FREE shipping on orders over $295 and under 70 lbs

(No reviews yet) Write a Review
Product Code:
CHL281GBKVPB8XD
Condition:
New
Availability:
Usually Ships in 3 to 5 Business Days
Adding to cart… The item has been added
The Chelsea 281GBKVP-B8XD or 281GBKVPB8XD is a 281 Series hydraulically shifted hot-shift power take-off built for automatic transmissions with a 10-bolt aperture, commonly fitted on Allison transmissions. It carries a single, continuous-duty torque rating and delivers nine speed ratios covering both low and high ranges. The ductile iron bearing cap is 117% stronger than gray iron, and an O-ring sealing configuration between the housing and bearing cap improves clamp load while reducing vibrational effects. The clutch pack features steel discs that are 80% thicker than the predecessor 280 Series, helping resist premature tooth wear. Rotatable cast-iron flanges reduce interference fit issues at pump clearance, and a positive stop on driveline outputs eliminates oil seal damage from coupling. A genuine Chelsea part sold by Pro Gear and Transmission. Call us to confirm proper fit for your application.

Features

Hydraulic hot-shift (PowerShift) operation for use with Allison 10-bolt aperture automatic transmissions
Ductile iron bearing cap rated 117% stronger than gray iron for increased durability
O-ring sealing configuration between housing and bearing cap reduces vibrational effects and improves clamp load
Enhanced clutch pack with steel discs 80% thicker than 280 Series predecessor to resist premature tooth wear
Nine speed ratios including both low and high speeds
Wet Spline Lubrication option extends shaft life 7 to 10 times compared to standard lubrication
SmartStart feature reduces shock load at start-up; Electronic Overspeed Control (EOC) protects driven equipment

Tech Specs

  • Shift Type: Hydraulic (PowerShift) Hot-Shift
  • Mounting Type: 10-Bolt
  • Transmission Compatibility: Allison automatic transmissions
  • Continuous Torque (Series Rating): 390 lb-ft (529 Nm)
  • Speed Ratios: Nine, including low and high
  • Lubrication: Wet Spline option available
  • Continuous Operation: Yes

Additional Information

Chelsea PTO 281 Series model break down

Parts Manual: Chelsea 281 Series PTO Parts Manual (PDF) — exploded views, item numbers and the full parts breakdown for this series.

!
