Chelsea PTO Assembly P/N: 281GDFJP-K5RB or 281GDFJPK5RB

281GDFJP-K5RB Chelsea PTO Assembly

Chelsea

Listing Price: $5,458.07
Sale Price: $3,995.29

This item qualifies for FREE shipping on orders over $295 and under 70 lbs

(No reviews yet) Write a Review
Product Code:
CHL281GDFJPK5RB
Condition:
New
Availability:
Usually Ships in 3 to 5 Business Days
Adding to cart… The item has been added
The Chelsea 281 Series Power Take-Off, part number 281GDFJP-K5RB or 281GDFJPK5RB, is a hydraulically shifted hot-shift PTO designed for automatic transmissions with a 10-bolt aperture, including Allison and Caterpillar transmissions. As an evolution of the 280 Series, the 281 Series introduces a ductile iron bearing cap rated 117% stronger than gray iron, an O-ring sealing configuration between the housing and bearing cap to improve clamp load, and clutch pack steel discs 80% thicker to resist premature tooth wear. Nine speed ratios cover both low and high ranges. Output options include SAE B and SAE C pump flanges, ISO 7652 pump flange, and driveline configurations. Common markets include fire and rescue, refuse, truck cranes, and pumper-cleaner applications. Call us to confirm proper fit for your transmission and application.

Features

Ductile Iron Bearing Cap - 117% stronger than gray iron predecessor
Hydraulic PowerShift (hot-shift) operation for 10-bolt automatic transmission apertures, including Allison
O-ring sealing configuration between housing and bearing cap improves clamp load and resists vibrational effects
Enhanced Clutch Pack - steel discs are 80% thicker to resist premature tooth wear
Nine speed ratios available, including low and high-speed ranges
Wet Spline Lubrication option provides 7 to 10 times greater shaft life
SmartStart feature reduces shock load at start-up for supported applications
Electronic Overspeed Control (EOC) protects driven equipment
Positive Stop for driveline outputs eliminates oil seal damage from coupling
Rotatable cast-iron flanges reduce interference clearance issues

Tech Specs

  • Mounting Type: 10-Bolt
  • Shift Type: Hydraulic (PowerShift / hot-shift)
  • Transmission Compatibility: Allison and Caterpillar automatic transmissions
  • Continuous Operation: Yes
  • Output Types: SAE B Pump Flange, SAE C Pump Flange, ISO 7652 Pump Flange, Driveline
  • Speed Ratios: Nine (including low and high)
  • Lubricant Options: Pressure Lube, Wet Spline
  • Series: Chelsea 281 Series

Additional Information

Chelsea PTO 281 Series model break down

Parts Manual: Chelsea 281 Series PTO Parts Manual (PDF) — exploded views, item numbers and the full parts breakdown for this series.

!
