The Chelsea PTO Assembly 281GGFJP-B3XV or 281GGFJPB3XV is a ten-bolt power take off unit built around nine speed ratios covering both low and high speed ranges. Bearing caps are ductile iron, rated 117% stronger than gray iron, and the O-ring sealing configuration reduces vibrational effects while improving clamp load. Rotatable cast-iron flanges lower interference fitment issues, and driveline outputs include a positive stop to prevent oil seal damage from coupling contact. The wet spline lubrication option extends shaft service life by 7 to 10 times. SmartStart reduces shock load at engagement, and the Electronic Overspeed Control (EOC) protects connected driven equipment. A hose is included with the assembly. Call us to confirm proper fit for your application.
Features
Ten-bolt PTO assembly configuration
Nine speed ratios including dedicated low and high speed ranges
Ductile iron bearing caps rated 117% stronger than gray iron
O-ring sealing reduces vibrational effects and improves clamp load
Electronic Overspeed Control (EOC) protects driven equipment
Wet spline lubrication option provides 7 to 10 times greater shaft life
Hose included with assembly
Tech Specs
- Ten-bolt mounting configuration
- Nine speed ratios including low and high speed
- Ductile iron bearing caps
- O-ring seal configuration
- Rotatable cast-iron flanges
- Wet spline lubrication option
- SmartStart shock load reduction
- Electronic Overspeed Control (EOC)
- Hose included
Additional Information
Parts Manual: Chelsea 281 Series PTO Parts Manual (PDF) — exploded views, item numbers and the full parts breakdown for this series.
