281GGFJW-G3RF Chelsea PTO Assembly

The Chelsea 281 Series Power Take-Off, part number 281GGFJW-G3RF or 281GGFJWG3RF, is a hydraulically shifted hot-shift PTO engineered for automatic transmissions with a 10-bolt aperture, including Allison transmissions. Built as an evolution of the 280 Series, the 281 Series features a ductile iron bearing cap rated 117% stronger than gray iron, an o-ring sealing configuration between the housing and bearing cap for improved clamp load, and an enhanced clutch pack with 80% thicker steel discs to resist premature tooth wear. Nine speed ratios cover both low and high ranges. Rotatable cast-iron flanges reduce interference fit issues, and the wet spline lubrication option extends shaft life by 7 to 10 times. Available for fire and rescue, refuse, pumper cleaner, and truck crane applications. Call us to confirm proper fit for your transmission and application.

Features

Hydraulic PowerShift (hot-shift) operation for Allison automatic transmissions with 10-bolt aperture
Ductile iron bearing cap - 117% stronger than gray iron predecessor
O-ring sealing configuration between housing and bearing cap reduces vibrational effects and improves clamp load
Enhanced clutch pack with 80% thicker steel discs to resist premature tooth wear
Nine speed ratios including dedicated low and high speeds
Wet spline lubrication option provides 7 to 10 times greater shaft life
SmartStart feature reduces shock load at start-up; Electronic Overspeed Control (EOC) protects driven equipment
Rotatable cast-iron flanges reduce pump clearance interference; positive stop for driveline outputs eliminates oil seal damage

Tech Specs

• Mounting Type: 10-Bolt
• Shift Type: Hydraulic PowerShift (Hot-Shift)
• Compatible Transmission Manufacturer: Allison
• Continuous Torque Rating: 390 lb-ft (529 Nm) - see application pages for actual torque rating
• Intermittent Torque Range: 301 to 400 lb-ft (501+ Nm)
• Output Power: 56+ HP (51+ kW)
• Shaft Power: 37 HP at 500 RPM / 74 HP at 1000 RPM (28 kW at 500 RPM / 55 kW at 1000 RPM)
• Output Types Available: SAE B pump flange, SAE C pump flange, ISO 7652 pump flange, driveline
• Output Shaft Options: SmartStart round shaft (1-1/4 in. with 5/16 in. key), 3/4 in. 11-tooth pump spline, SAE B 7/8 in. 13-tooth pump spline, SAE C 1-1/4 in. 14-tooth pump spline, DIN 5462 pump spline, 1410 companion flange, DIN 120 flange, DIN 100 flange
• Lubricant Options: Pressure lube (P), Wet Spline (W)
• Speed Ratios: Nine ratios including low and high speeds
• Series: Chelsea 281

Additional Information

Parts Manual: Chelsea 281 Series PTO Parts Manual (PDF) — exploded views, item numbers and the full parts breakdown for this series.
