The Chelsea 340 Series Power Take-Off, part number 340SFAHX-A4XD or 340SFAHXA4XD, is a reversible, 6-bolt mount PTO designed for vocational truck applications requiring both forward and reverse rotation. Shift type is lever/mechanical, and the output shaft is a 1-1/4" round with keyway. Intermittent torque is rated up to 200 lb-ft (271 Nm); check application pages for actual torque ratings for your setup. Output power runs 36-45 HP (21-30 kW), with shaft power of 19 HP at 500 RPM and 38 HP at 1000 RPM. Compatible transmission manufacturers include Eaton/Fuller, Hino, GM, Volvo/Mack, ZF, and other 6-bolt aperture manual transmissions. The cast iron housing and ball bearing output are characteristic of the 340 Series. Call us to confirm proper fit for your application.
Features
Reversible, 6-bolt mounting fits most manual transmissions with a 6-bolt aperture
Lever/mechanical shift type
1-1/4" round output shaft with keyway
Intermittent torque up to 200 lb-ft (271 Nm); check application pages for actual torque ratings
Output power 36-45 HP (21-30 kW); shaft power 19 HP at 500 RPM, 38 HP at 1000 RPM
Ball bearing output and rugged cast iron housing with removable cover plate for backlash adjustment
Tech Specs
- Intermittent Torque: Up to 200 lb-ft (271 Nm) - Check Application Pages for Actual Torque Ratings
- Mounting Type: Reversible, 6-Bolt
- Output Shaft Type: 1-1/4" Round with 5/16" Key
- Output Power: 36-45 HP (21-30 kW)
- Shift Type: Lever, Mechanical
- Compatible Transmission Manufacturers: Eaton/Fuller, Hino, GM, Volvo/Mack, ZF, Other
- Shaft Power: 19 HP at 500 RPM, 38 HP at 1000 RPM (14 kW at 500 RPM, 28 kW at 1000 RPM)
- Lubrication: No Pressure Lube
- Housing: Cast Iron
Additional Information
Parts Manual: Chelsea 340 Series PTO Parts Manual (PDF) — exploded views, item numbers and the full parts breakdown for this series.
