The Chelsea 340 Series Power Take-Off Assembly, part number 340XFARX-Y5XD or 340XFARXY5XD, is built for vocational truck applications that need forward and reverse PTO capability. It mounts to most manual transmissions with a 6-bolt aperture and fits transmissions from Eaton/Fuller, Volvo/Mack, ZF, Hino, and GM. The lever-actuated mechanical shift drives a 1-1/4" round keyed output shaft rated at 19 HP at 500 RPM and 38 HP at 1000 RPM, with intermittent torque up to 200 lb-ft (check application pages for actual torque ratings). The reversible mounting orientation suits tight under-cab installations. Common applications include oil field and logging equipment. Call us to confirm proper fit for your transmission.
Features
Reversible 6-bolt mounting fits most manual transmission apertures, including Eaton/Fuller, Volvo/Mack, ZF, Hino, and GM
Lever and mechanical shift actuation
1-1/4" round output shaft with 5/16" key
Intermittent torque rating up to 200 lb-ft (271 Nm); verify rating on application pages
Shaft power: 19 HP at 500 RPM, 38 HP at 1000 RPM
Cast iron housing with ball bearing output and removable cover plate for backlash adjustment
Tech Specs
- Intermittent Torque: Up to 200 lb-ft (271 Nm) - Check Application Pages for Actual Torque Ratings
- Mounting Type: Reversible, 6-Bolt
- Output Shaft Type: 1-1/4" Round with 5/16" Key
- Output Power: 36-45 HP (21-30 kW)
- Shift Type: Lever, Mechanical
- Transmission Manufacturer: Eaton/Fuller, Volvo/Mack, ZF, Hino, GM, Other
- Shaft Power: 19 HP (500 RPM), 38 HP (1000 RPM); 14 kW (500 RPM), 28 kW (1000 RPM)
- Continuous Operation: Yes, with 30% de-rating
