The Chelsea 442 Series Power Take-Off Assembly, part number 442XFAHX-A3GA or 442XFAHXA3GA, is a 6-bolt mount PTO built for light-to-medium duty vocational applications including dump trucks, tow trucks, and service trucks. This unit runs a 0.391:1 gear ratio with air shift actuation and a 1-1/4" round standard output shaft. Mounting uses the standard configuration with metric studs, and the assembly carries no pressure lube requirement. The cast iron housing pairs with tapered cone bearings on the output shaft for long-term durability. The 360-degree rotatable output flange adds installation flexibility when clearance is tight. Call us to confirm proper fit for your transmission and application.
Features
Chelsea 442 Series, 6-bolt transmission mount with metric studs
Air shift actuation
0.391:1 gear ratio
1-1/4" round standard output shaft, no pressure lube required
Cast iron housing with tapered cone bearings for extended service life
360-degree rotatable output flange for installation clearance flexibility
Tech Specs
- Product Series: 442
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs
- Shift Type: Air Shift
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
