The Chelsea 442 Series Power Take-Off assembly, part number 442XFAHX-A4XD or 442XFAHXA4XD, is a 6-bolt, standard-mount unit configured with metric studs and air shift actuation. The gear ratio is 0.391:1, with a 1-1/4" round standard output shaft and no-pressure-lube lubrication. The cast iron housing and tapered cone output shaft bearings give the 442 Series its class-leading torque rating. Greaseable output shafts and a 360-degree rotatable flange design allow for flexible installation clearance. Cross-references for this part include 1450-442XFAHXA4XD, CHL442XFAHXA4XD, S-10986, and TG6SU6806A2BX. Call us to confirm proper fit for your application.
The Chelsea 442 Series is suited for light-to-medium duty vocational applications including tow trucks, service trucks, dump trucks, and aerial equipment. The series offers eleven internal speed ratios and multiple shift options, making it adaptable across a range of 6-bolt transmission applications. Refer to Chelsea application pages to confirm torque ratings for your specific installation.
Features
Chelsea 442 Series, 6-bolt standard mount with metric studs
Air shift actuation
0.391:1 gear ratio
1-1/4" round standard output shaft, no-pressure-lube configuration
Cast iron housing with tapered cone output shaft bearings
Greaseable output shafts and rotatable output flanges for installation flexibility
Tech Specs
- Product Series: 442
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs (6-Bolt)
- Shift Type: Air Shift
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
Additional Information
Cross-reference part numbers: 1450-442XFAHXA4XD, 1450442XFAHXA4XD, CHL442XFAHXA4XD, S-10986, S10986, TG6SU6806A2BX.The Chelsea 442 Series is suited for light-to-medium duty vocational applications including tow trucks, service trucks, dump trucks, and aerial equipment. The series offers eleven internal speed ratios and multiple shift options, making it adaptable across a range of 6-bolt transmission applications. Refer to Chelsea application pages to confirm torque ratings for your specific installation.
