The Chelsea 442XFAHX-M5AF (also listed as 442XFAHXM5AF) is a 442 Series two-gear, six-bolt power take-off assembly built for heavy-duty truck applications. It runs a 0.391:1 gear ratio and uses air shift engagement with a standard mount configuration featuring metric studs. The output is a 1-1/4" round standard shaft, and the unit operates without a pressure lube system. The cast iron housing handles the demands of commercial work cycles, while rotatable output flanges give added clearance flexibility during installation. Greaseable output shafts support extended service intervals. Call us to confirm proper fit for your application.
Features
442 Series, two-gear, six-bolt PTO assembly
Gear ratio: 0.391:1
Shift type: Air shift
Standard mount with metric studs
1-1/4" round standard output shaft
Cast iron housing with rotatable output flanges and greaseable output shafts
Tech Specs
- Product Series: 442
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Shift Type: Air Shift
- Mounting Option: Standard Mount with Metric Studs
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3 (Two-Gear, Six-Bolt)
- Lubricant: No Pressure Lube
