The Chelsea 442 Series Power Take-Off, part number 442XSABX-Y3XK or 442XSABXY3XK, is a 6-bolt mount PTO built for light-to-medium duty vocational applications. This unit runs a 0.391:1 gear ratio with air shift actuation and delivers power through a 1-1/4" round standard output shaft. Mounting is standard with metric studs, and the unit uses no pressure lube. The cast iron housing and tapered cone bearings on the output shaft keep service life long across demanding cycles. The 442 Series fits virtually all existing 6-bolt transmission applications and is well matched to service trucks, dump trucks, tow trucks, and small aerial equipment. Call us to confirm proper fit for your transmission.
Features
Chelsea 442 Series, 6-bolt standard mount with metric studs
Gear ratio: 0.391:1
Shift type: Air Shift
Output: 1-1/4" round standard shaft
No pressure lube configuration
Cast iron housing with tapered cone bearings on the output shaft
Rotatable output flanges for improved installation clearance
Greaseable output shafts
Tech Specs
- Product Series: 442
- Gear Ratio: 0.391:1
- Shift Type: Air Shift
- Mounting Option: Standard Mount with Metric Studs (6-Bolt)
- Output Option: 1-1/4" Round Standard Shaft
- Lubricant: No Pressure Lube
- Input Gear Designator: AH
- Assembly: 3
