The Chelsea 442 Series Power Take-Off, part number 442XSESX-A5XY or 442XSESXA5XY, is a 6-bolt transmission-mount PTO built for light-to-medium duty vocational applications including dump trucks, tow trucks, and service trucks. This unit runs a 0.391:1 gear ratio with air shift actuation and a 1-1/4" round standard output shaft. Mounting uses standard mount with metric studs. The housing requires no pressure lube. Tapered cone bearings on the output shaft and a cast iron housing are characteristic of the 442 Series, which supports up to 36 output configurations and 11 internal speed ratios across the product line. Call us to confirm proper fit for your transmission and application.
Features
Chelsea 442 Series, 6-bolt transmission mount with metric studs
Gear ratio: 0.391:1
Shift type: Air shift
Output: 1-1/4" round standard shaft
No pressure lube required
Cast iron housing with tapered cone bearings for extended service life
Low-profile shift cover and greaseable, rotatable output shaft for improved clearance
Tech Specs
- Product Series: 442
- Gear Ratio: 0.391:1
- Input Gear Designator: AH
- Shift Type: Air Shift
- Mounting Option: Standard Mount with Metric Studs (6-Bolt)
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
