The Chelsea 442 Series Power Take-Off, part number 442XXKBX-P5RF or 442XXKBXP5RF, is a 6-bolt mount PTO built for light-to-medium duty vocational applications including dump trucks, tow trucks, and service trucks. This unit uses 12V electric/air shift actuation and a rotatable SAE B 2-bolt flange with a 1" 15-tooth SAE BB shaft. Mounting uses the standard configuration. The housing carries no pressure lube requirement. Tapered cone bearings on the output shaft and a cast iron housing give the 442 Series its class-leading torque capacity and service life. The low-profile shift cover and 360-degree rotatable output flanges make installation more flexible in tight cab or frame configurations. Call us to confirm proper fit for your specific transmission and application.
Features
Chelsea 442 Series, 6-bolt transmission mount
12V electric/air shift actuation
Rotatable SAE B 2-bolt flange with a 1" 15-tooth SAE BB shaft
Cast iron housing with tapered cone bearings on output shaft
Low-profile shift cover and 360-degree rotatable output flanges for installation flexibility
Tech Specs
- Product Series: 442
- Mounting Option: Standard Mount (X)
- Gear Ratio Code: X (38/21)
- Input Gear Designator: KB
- Lube Option: No Pressure Lube (X)
- Shift Option: 12V DC Electric/Air Shift (P)
- Assembly Arrangement: 5
- Output Option: Rotatable SAE B 2-Bolt Flange, SAE BB Shaft (1" 15T) (RF)
