The Chelsea 489 Series Power Take-Off Assembly, part number 489XUAHX-A6AF or 489XUAHXA6AF, is a wire/cable mechanical shift PTO built on an 8-bolt mount that bolts directly to the transmission opening without an adapter plate, eliminating a common leak path. Compatible with Eaton/Fuller, Volvo/Mack, and other manual transmissions with an 8-bolt PTO aperture. The one-piece cast iron housing delivers the same intermittent torque capacity as the 442 Series. Output shaft is a 1-1/4" round shaft with key. Shaft power measures 24 HP at 500 RPM and 48 HP at 1,000 RPM, with output power in the 46-55 HP range. Call us to confirm proper fit for your transmission.
Features
8-bolt one-piece cast iron housing mounts directly to transmission opening, no adapter plate required
Wire/cable mechanical shift with electric-over-air shift option available
1-1/4" round output shaft with key; greaseable output options to reduce spline fretting and corrosion
Shaft power: 24 HP at 500 RPM, 48 HP at 1,000 RPM
Intermittent torque rating: 201-300 lb-ft (301-400 Nm) series range
Kit-style design with internal parts common to the Chelsea 442 Series for easier servicing
Tech Specs
- PRODUCT SERIES: 489
- MOUNTING TYPE: 8-Bolt (direct to transmission, no adapter plate)
- SHIFT TYPE: Wire/Cable Mechanical
- OUTPUT SHAFT TYPE: 1-1/4" Round with Key
- OUTPUT POWER: 46-55 HP (31-40 kW)
- SHAFT POWER: 24 HP (500 RPM), 48 HP (1,000 RPM) / 18 kW (500 RPM), 36 kW (1,000 RPM)
- INTERMITTENT TORQUE: 201-300 lb-ft / 301-400 Nm (check application pages for actual torque ratings)
- TRANSMISSION COMPATIBILITY: Eaton/Fuller, Volvo/Mack, and other manual transmissions with 8-bolt aperture
- LUBRICANT: X = No Pressure Lube, P = Pressure Lube
