The Chelsea 680 Series Power Take-Off Assembly, part number 680XQAHX-P3AF or 680XQAHXP3AF, is a medium-to-heavy-duty 8-bolt mount PTO engineered for higher-torque demands including pneumatic blower applications. It mounts to transmissions from Eaton/Fuller, Volvo/Mack, and other manufacturers with an 8-bolt PTO aperture, and includes a deep-mount housing option suited for Mack installations. The 1-1/4" round output shaft with keyway delivers wire/cable mechanical shift operation. Intermittent torque capacity spans 301-400 lb-ft (501+ Nm), with shaft power rated at 36 HP at 500 RPM, 71 HP at 1,000 RPM, and 107 HP at 1,500 RPM. The cast iron housing uses tapered cone bearings on the output shaft and tapered bearings on the input shaft for strong load-bearing capability. A genuine Chelsea part available from Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
8-Bolt mounting for broad coverage of manual transmissions with 8-bolt PTO apertures
Deep-mount housing option for Mack transmission applications
1-1/4" round output shaft with keyway
Wire/cable mechanical shift type
Intermittent torque rated at 301-400 lb-ft (501+ Nm); check application pages for actual torque ratings
Cast iron housing with tapered cone bearings on output shaft and tapered input shaft bearings for high load capacity
Tech Specs
- Mounting Type: 8-Bolt
- Shift Type: Wire/Cable, Mechanical
- Output Shaft Type: 1-1/4" Round with Key
- Intermittent Torque: 301-400 lb-ft / 501+ Nm (375 lb-ft / 508 Nm - check application pages for actual torque ratings)
- Output Power: 56+ HP / 51+ kW
- Shaft Power: 36 HP (500 RPM), 71 HP (1,000 RPM), 107 HP (1,500 RPM) / 27 kW (500 RPM), 53 kW (1,000 RPM), 80 kW (1,500 RPM)
- Transmission Manufacturer Compatibility: Eaton/Fuller, Volvo/Mack, Other
