The Chelsea 880XMAHX-A3GS or 880XMAHXA3GS is an 8-bolt Power Take-Off assembly with lever mechanical shift, designed for Volvo/Mack, Allison, Eaton/Fuller, and other transmission applications. The output shaft is a 1-1/2" 10-spline configuration with a 1410 companion flange, supporting dual-pump mounting so a hydraulic pump can be driven from each end of the PTO. Intermittent torque capacity reaches 500 lb-ft (678 Nm), and shaft power output is rated at 48 HP (36 kW) at 500 RPM and 95 HP (71 kW) at 1000 RPM. The cast iron housing includes a simple backlash adjustment to reduce installation time. Call us to confirm proper fit for your specific transmission and application.
Features
8-bolt mounting configuration
Lever mechanical shift type
1-1/2" 10-spline output shaft with 1410 companion flange
Dual-pump output for mounting a pump on each end of the PTO
Intermittent torque rating up to 500 lb-ft (678 Nm)
Shaft power: 48 HP at 500 RPM, 95 HP at 1000 RPM
Cast iron housing with simple backlash adjustment
Tech Specs
- Intermittent Torque: 500 lb-ft (678 Nm) - Check Application Pages for Actual Torque Ratings
- Transmission Manufacturer: Volvo/Mack, Allison, Eaton/Fuller, Other
- Shift Type: Lever Mechanical
- Output Power: 56+ HP (51+ kW)
- Output Shaft Type: 1-1/2" - 10T Spline with 1410 Companion Flange
- Mounting Type: 8-Bolt
- Shaft Power: 500 RPM: 48 HP (36 kW) | 1000 RPM: 95 HP (71 kW)
