6-4-6931-1X or 6469311X Dana Spicer end yoke, a manual transmission output end yoke from the 1710 series. This steel assembly has a 10 spline splined hole with a 3.000 in. length through the hole, a 3.750 in. hub diameter and a 2.750 in. major diameter. The slinger/plug is included.
The end yoke sits at the end of the driveline, carries the universal joint and passes torque from the transmission output on to the driveshaft. A worn or distorted yoke can look like general driveline trouble that a new U-joint or driveshaft will not cure, so look at the yoke when you are chasing a driveline problem. Call us to confirm proper fit for your application.
Features
Manual transmission output end yoke, 1710 series, steel assembly
10 spline splined hole, non-involute spline, 2.750 in. major diameter
Hub diameter 3.750 in., length through hole 3.000 in., center line to end hub 5.750 in.
Outside yoke dimension 6.190 in., yoke bearing dimension 1.938 in.
Slinger/plug included
Carries the U-joint and passes torque from the transmission output to the driveshaft
Tech Specs
- Series 1710
- Invoice END YOKE ASSY
- Spline Count 10
- Yoke Style HR
- Hub Diameter R 3.750
- C/L To End Hub S 5.750
- Type Splined Hole
- Outside Yoke Dimension (In) E 6.190
- Yoke Bearing Dimension (In) D 1.938
- Major Diameter 2.750
- Involute Spline N
- VMRS 026001083
- Length Thru Hole Q 3.000
- Includes Slinger/Plug Y
- Assembly Y
- Material Steel
