Genuine Dana Spicer Svl Axle Shaft for light axle application P/N: 2022589-1 or 20225891. Genuine parts, premium service! Repair your vehicle with authentic parts! Authentic Genuine Dana Spicer parts, delivered globally. Need assistance? Our experts have got you covered!
Tech Specs
- Axle Model GM 8.2/8.5
- Material Steel
- Invoice SVL REAR AXLE SHAFT
- Axle Cover Bolt Hole Qty 10
- ABS/Non-ABS Non-ABS
- Location LH/RH
- Length (IN) 29.180
- Axle Length (In) 29.180
- Spline Count 28 Inboard
- Axle Spline Count 28 Inboard
- Bolt Pattern 5 X 4.75
- Wheel Stud Hole Diameter (In) 0.453
- Brake Pilot Diameter (In) 2.776
- Bearing Pilot Diameter (In) 1.399
- Cover Bolt Quantity 10
- Includes Tone N
- Axle Length (Mm) 741.400
- ABS Sensor Ring Included No
- ABS Sensor Ring Installed N
- Axle Shaft Included Y
- Axle Type Complete Assembly
- Bearing Included N
- Full-Floating Or Semi-Floating Semi-Floating
- Inner Axle Included Y
- Number Of Wheel Lugs 5
- Outer Axle Included Y
- Quantity 1
- Retainer Ring Included N
- Seal Included N
- Seal Kit Included N
- U-Joint Included N
- Wheel Bearing Included N
- Wheel Bolt Prep Kit Included N
- Wheel Nuts Included N
- Wheel Studs Included N
- Length (MM) 741.400
