The Dana Spicer 2022589-2 or 20225892 is a complete semi-floating SVL rear axle shaft assembly for Dana 44 axles. It measures 29.680 inches (753.872 mm) in length and carries 28 inboard splines. The wheel flange runs a 5x4.75 bolt pattern with five lug positions, a wheel stud hole diameter of 0.453 in., a brake pilot diameter of 2.776 in., and a bearing pilot diameter of 1.398 in. The axle cover uses a 10-bolt hole pattern. This shaft is supplied without a bearing, seal, ABS sensor ring, retainer ring, or wheel studs - confirm what your application requires before ordering. Call us to confirm proper fit for your specific vehicle and Dana 44 configuration.
Features
Dana 44 semi-floating axle shaft, complete assembly
29.680 in. (753.872 mm) shaft length
28 inboard splines
5x4.75 bolt pattern, 5-lug flange
Brake pilot diameter 2.776 in., bearing pilot diameter 1.398 in.
10-bolt axle cover pattern; no ABS sensor ring
Tech Specs
- Axle Model: Dana 44
- Material: Steel
- Axle Type: Complete Assembly
- Float Type: Semi-Floating
- Length: 29.680 in. (753.872 mm)
- Spline Count: 28 Inboard
- Bolt Pattern: 5 x 4.75
- Number of Wheel Lugs: 5
- Wheel Stud Hole Diameter: 0.453 in.
- Brake Pilot Diameter: 2.776 in.
- Bearing Pilot Diameter: 1.398 in.
- Axle Cover Bolt Holes: 10
- ABS Sensor Ring: Not included
- Bearing: Not included
- Seal: Not included
- Retainer Ring: Not included
- Wheel Studs: Not included
- Location: LH or RH (verify application)
- Quantity: 1
