The Dana Spicer SVL rear axle shaft, part number 2022589-3 or 20225893, is a complete semi-floating axle shaft assembly for Dana 44 axles. Shaft length is 30.060 inches (763.600 mm) with 28 inboard splines. The 5-lug wheel flange uses a 5 x 4.75-inch bolt pattern, a 0.453-inch wheel stud hole diameter, and a 2.776-inch brake pilot diameter. Bearing pilot diameter measures 1.398 inches. This shaft fits left-hand or right-hand positions, suits non-ABS applications, and is designed for a 10-bolt axle cover. Inner and outer axle shafts are both included in the assembly. This is a genuine Dana Spicer part sold by Pro Gear and Transmission. Call us to confirm proper fitment before ordering.
Features
Dana 44 axle application, non-ABS, semi-floating design
30.060 in. (763.600 mm) shaft length
28 inboard splines
5-lug, 5 x 4.75 in. bolt pattern
Brake pilot diameter: 2.776 in. | Bearing pilot diameter: 1.398 in.
Complete assembly - fits LH or RH position; bearing, seal, and retainer ring sold separately
Tech Specs
- Axle Model Dana 44
- Material Steel
- Axle Type Complete Semi-Floating Assembly
- Location Left-Hand or Right-Hand
- ABS / Non-ABS Non-ABS
- ABS Sensor Ring Included No
- Axle Length 30.060 in. (763.600 mm)
- Spline Count (Inboard) 28
- Bolt Pattern 5 x 4.75 in.
- Wheel Stud Hole Diameter 0.453 in.
- Brake Pilot Diameter 2.776 in.
- Bearing Pilot Diameter 1.398 in.
- Axle Cover Bolt Quantity 10
- Number of Wheel Lugs 5
- Inner Axle Included Yes
- Outer Axle Included Yes
- Bearing Included No
- Seal Included No
- Retainer Ring Included No
- Wheel Studs Included No
- Wheel Nuts Included No
- U-Joint Included No
- Quantity 1
