The Eaton Advantage Self-Adjust clutch, part number 309701-91 or 30970191, is a 15.5-inch heavy-duty manual transmission clutch rated at 1,650 ft-lb of torque. It features ceramic friction material across 6 friction pads on 2 discs, a 2.00-inch 10-spline input shaft, and hydraulic linkage compatibility. The self-adjusting design eliminates manual free-pedal adjustments over the service life of the clutch. With 9 damper springs and no pre-damper, this unit is engineered for heavy-duty vehicle applications. Cross-references include 209701-91 and CL109601-92. Call us to confirm proper fit for your application.
Shipped on pallet.
Features
15.5-inch clutch diameter rated at 1,650 ft-lb torque
Ceramic facing material with 6 friction pads across 2 discs
2.00-inch 10-spline input shaft
Hydraulic linkage compatible
9 damper springs, no pre-damper
Self-adjusting design for heavy-duty manual transmission applications
Tech Specs
- Clutch Size: 15.5 in
- Torque Rating: 1,650 ft-lb
- Input Shaft Size: 2.00 in - 10 spline
- Number of Discs: 2
- Friction Pad Count: 6
- Facing Material: Ceramic
- Hydraulic Linkage: Yes
- Pre-Damper: No
- Damper Spring Count: 9
- Transmission Type: Manual
- Vehicle Classification: Heavy Duty
