The Eaton K-3768CL or K3768CL is a clutch installation kit for heavy-duty transmissions. The kit includes an input shaft assembly, input shaft bearing, pilot bearing, front bearing cover, clutch release yoke (CL REL 105-C-137), clutch brake disc assembly, four bushings, two snap rings, and a gasket kit (K-3453). Cross-references include 3088-K3768, FUL K3768, M-2117, and ZBFK3768. This is a genuine Eaton part sold by Pro Gear and Transmission. Call us to confirm proper fit for your application before ordering.
Features
Includes input shaft assembly (S-2890) and input shaft bearing (part 4308451)
Pilot bearing (part 5566505) and front bearing cover (part 20550) included
Clutch release yoke CL REL 105-C-137 (part 85533) and clutch brake disc assembly (part 85541) included
Four bushings (part 12815) and two snap rings (parts 14750 and 16980) in the kit
Gasket kit K-3453 included
Cross-references: 3088-K3768, FUL K3768, M-2117, ZBFK3768
Tech Specs
- Part Number: K-3768CL or K3768CL
- Brand: Eaton
- Kit Contents: Input shaft assembly, input shaft bearing, pilot bearing, front bearing cover, clutch release yoke (CL REL 105-C-137), clutch brake disc assembly, 4x bushings, 2x snap rings, gasket kit (K-3453)
- Cross References: 3088-K3768, 3088K3768, FUL K3768, FULK3768, K3768, K3768FUL, M-2117, M2117, ZBFK3768
- Unit of Measure: Each
