The Eaton Fuller Cross Shaft Assembly Kit K-4036 or K4036 is a genuine Eaton kit covering the complete cross-shaft assembly for manual transmissions. The kit ships as a single unit and contains all major components needed for a full cross-shaft service: two bushings (p/n 12815), one grease seal (p/n 4306210), one square-socket plug (p/n 4306338), one ECA actuator shaft (p/n 4306456), one clutch-release shaft (p/n 4306458), three ty-raps (p/n 5559348), a roller yoke assembly (p/n A-8133), an instruction letter, two hex-head screws (p/n X-8-564), four capscrews (p/n X-8L-609), and two capscrews (p/n X-8L-722). Cross-references include 3088-K4036, 3088K4036, 5314367, FUL K4036, and FULK4036. Contact Pro Gear and Transmission to confirm fitment for your specific transmission model.
Features
Complete cross-shaft service kit: ECA actuator shaft, clutch-release shaft, and roller yoke assembly included
Two bushings (p/n 12815) and one grease seal (p/n 4306210) included for a full rebuild
Square-socket plug, hex-head screws, and two capscrew sizes cover all hardware requirements
Three ty-raps and a printed instruction letter (p/n L-2008-01) packaged with the kit
Cross-references: 3088-K4036, 3088K4036, 5314367, FUL K4036, FULK4036
Sold as a single kit (unit of measure: EACH) by Pro Gear and Transmission
Tech Specs
- Kit Number: K-4036 or K4036
- Kit Type: Cross Shaft Assembly Kit
- Bushing (p/n 12815): x2
- Grease Seal (p/n 4306210): x1
- Plug, Square Socket (p/n 4306338): x1
- Shaft, Actuator, ECA (p/n 4306456): x1
- Shaft, Clutch Release (p/n 4306458): x1
- Ty-Rap (p/n 5559348): x3
- Roller Yoke Assembly (p/n A-8133): x1
- Screw, Hex Head (p/n X-8-564): x2
- Capscrew (p/n X-8L-609): x4
- Capscrew (p/n X-8L-722): x2
- Instruction Letter (p/n L-2008-01): x1
- Cross References: 3088-K4036, 3088K4036, 5314367, FUL K4036, FULK4036, K-4036, K4036
- Unit of Measure: EACH
