K-1503 Eaton Fuller Small Parts Kit

The Eaton Fuller K-1503 or K1503 Small Parts Kit is a genuine OEM kit designed for Fuller transmission rebuilds. The kit contains 15 distinct components: three springs (p/n 1064), two splined gear spacers (p/n 14273 x1 and p/n 14749 x2), five snap rings (p/n 14289, p/n 14750 x3, and p/n 16763), four washers (p/n 14711 x2, p/n 14712, p/n 14713), one 4300512 washer, two flat output shaft keys (p/n 14736), one M-shaft key assembly (p/n A-3456), one interlock pin (p/n 1634), three 1/2-inch steel balls (p/n X14 800), and one instruction letter (p/n L-1680). Having the correct small parts on hand before a teardown keeps a rebuild on schedule. Call us to confirm this kit fits your specific Fuller transmission application.

Features

Genuine Eaton Fuller K-1503 or K1503 Small Parts Kit
Includes three springs, five snap rings, and four assorted washers
Two splined gear spacers plus one M-shaft key assembly (A-3456)
Two flat output shaft keys (p/n 14736) and one interlock pin (p/n 1634)
Three 1/2-inch steel balls (p/n X14 800)
Instruction letter (p/n L-1680) included in kit

Tech Specs

• Kit Number: K-1503 or K1503
• Kit Type: Small Parts Kit
• Brand: Eaton Fuller
• Component Count: 15 distinct part numbers
• Includes: Springs x3, Snap Rings x5, Washers x4 (plus one 4300512 washer), Splined Gear Spacers x3, Output Shaft Flat Keys x2, M-Shaft Key Assembly x1, Interlock Pin x1, Steel Balls 1/2 in. x3, Instruction Letter x1

Additional Information

Kit Bill of Materials (Eaton Fuller K-1503):
1064 - Spring x3
14273 - Spacer, Gear Splined x1
14289 - Snap Ring x1
14711 - Washer x2
14712 - Washer x1
14713 - Washer x1
14736 - Key, Output Shaft Flat x2
14749 - Spacer, Gear Splined x2
14750 - Snap Ring x3
1634 - Pin, Interlock x1
16763 - Snap Ring x1
4300512 - Washer x1
A-3456 - Key Assembly, M-Shaft x1
X14 800 - Ball, Steel, 1/2 in. x3
L-1680 - Letter, Instruction x1
