K-1512 Eaton Fuller Small Parts Kit

The Eaton Fuller K-1512 or K1512 Small Parts Kit is a genuine Eaton Fuller transmission hardware kit containing 21 individual components. The kit includes six springs (three each of part nos. 1064 and 14897, plus a compression spring and a separate spring), seven snap rings across five part numbers, a range slave actuating pin (qty 2, two different part numbers), an interlock pin, a spacer, three 1/2-inch steel balls, and an assortment of washers and lock washers. An instruction letter is included. Call us to confirm proper fit for your specific transmission model and build.

Features

21-piece genuine Eaton Fuller transmission small parts kit
Includes six springs: part nos. 1064 (x3), 14897 (x3), plus compression spring 21268 and spring 6392
Seven snap rings covering five distinct part numbers (14286, 14993, 15050, 15980, 15994)
Range slave actuating pins (part nos. 15102 and 20649) and interlock pin (part no. 1634)
Three 1/2-inch steel balls (X14 800) plus spacer, washers, and 3/8 special lock washers
Instruction letter (L-1680) included in the kit

Additional Information

Kit Bill of Materials (per Eaton Inforanger):
1064 - Spring x3
14286 - Snap Ring x2
14897 - Spring x3
14993 - Snap Ring x1
15050 - Snap Ring x2
15086 - Spacer x1
15102 - Pin, Range Slave Actuating x1
15446 - Washer x2
15748 - Lock Washer, 3/8 Special x2
15980 - Snap Ring x1
15994 - Snap Ring x1
16247 - Washer x1
1634 - Pin, Interlock x1
17259 - Washer x1
17260 - Washer x1
20649 - Pin, Range Slave Actuating x1
21268 - Spring, Compression x1
5946 - Washer x1
6392 - Spring x1
L-1680 - Instruction Letter x1
X14 800 - Ball, Steel, 1/2 in. x3
