The Fabco Maxx22T Caliper SE, part number 640-222-007-0NX or 6402220070NX, is a left-hand, single-piston air disc brake caliper engineered to OEM specifications for the Hendrickson Maxx 22T application. The axial chamber mount is angled at 12 degrees, with an axial chamber position and an A-B distance of 1-11/16 in. The 6-hole carrier bolts to M16 x 2.0 mounting hardware, and the caliper is designed to work with a 415 mm rotor. The mount pattern forms an inverted-triangle arrangement. FMSI designation is 1777. Compatible disc pad numbers include MMD1777M22TAG, 6402229272, and ED1777TS (pad length 8.28 in.; pads not included). Cross-references: Hendrickson S35973L and TDA6402220070NX. Available at Pro Gear and Transmission - call us to confirm fitment for your application.
Non returnable item
A refundable core charge of $462.00 applies to this item and will be collected at checkout. The core charge is refunded upon receipt of your returned core, subject to its condition; customer is responsible for return shipping. Call us at (877) 776-4600 for details.
Features
Left-hand, single-piston disc brake caliper for Hendrickson Maxx 22T
Axial chamber mount and chamber position, angled at 12 degrees
6-hole carrier with M16 x 2.0 mounting hardware; inverted-triangle bolt pattern
A-B distance: 1-11/16 in.; compatible with 415 mm rotor
FMSI 1777; compatible pad numbers MMD1777M22TAG, 6402229272, and ED1777TS (pad length 8.28 in. - pads not included)
Cross-references Hendrickson S35973L and TDA6402220070NX; OEM: Wabco Maxx
Tech Specs
- Model: Maxx 22T
- OEM: Wabco
- Application: Hendrickson Maxx 22T
- Left or Right: Left
- Numbers of Pistons: 1
- Chamber Mount: Axial, 12 degrees
- Chamber Position: Axial
- Brake Chamber Angle: 12 degrees
- Axial or Radial Mount: Axial
- Carrier Mounting Holes: 6
- Mounting Hole Size: M16 x 2.0
- Distance A-B: 1-11/16 in.
- Pad Length: 8.28 in.
- Pads Included: No
- FMSI: 1777
- Compatible Rotor: 415 mm
- Mount Pattern: Inverted-triangle arrangement
- Related Disc Pad Numbers: MMD1777M22TAG; 6402229272; ED1777TS
- Related Core Group: MC350
- Related Core Number: XM2651
- Marketing Group: Wabco Maxx
- Cross-Reference - Hendrickson: S35973L
- Cross-Reference - Other: TDA6402220070NX
- Hardware Kit: Not sold separately
