Fabco bearing spacer ring 756-0249-003 or 7560249003 measures 3.00 by 2.52 by .408 thick. Our TC-270 parts list carries it at item 38 of the upper shaft assembly for models with PTO, down at the output end of that shaft where the bearing cone and cup sit in their carrier ahead of the output seal. It is one of a graduated family of spacer thicknesses, and the footnote printed beside that item has the builder select a single ring from the family to set the end play with the output yoke or sealing ring installed. That makes the thickness the whole reason this number exists. Genuine Fabco from Pro Gear and Transmission.
Features
Bearing spacer ring, .408 thick
Face dimensions 3.00 by 2.52, per the factory call-out
Item 38 in the Fabco TC-270 upper shaft assembly for models with PTO
Sits at the output end with the bearing cone, cup and output seal
One of a graduated family, selected to set end play at the output yoke or sealing ring
Part number spelled 756-0249-003 or 7560249003
Tech Specs
- Part type: Bearing spacer ring
- Thickness: .408 in.
- Dimensions: 3.00 x 2.52 x .408
- Unit: Fabco TC-270 transfer case, upper shaft assembly with PTO
- Item number: 38
- UPC: 193174403149
Used in these Fabco Transfer Case model
