The Meritor front hub assembly, part number 05-15632-001 or 0515632001, is a conventional steer-axle hub designed for FF/FG axle series applications with a 14,600 lb GAWR rating. This hub-only unit comes equipped with a tone ring (ABS ring number 09-001940) and is configured for drum brake service. Key dimensional specs include an 11.25 in. wheel stud and drum bolt circle diameter on a 10-bolt pattern, a drum pilot diameter of 8.778/8.775 in., a wheel pilot diameter of 8.653/8.646 in., and a flange outer diameter of 13.00 in. Wheel stud hole and drum bolt size measure 0.904/0.906 in. The hub cap bolt circle is 4.50 in. on a 6-bolt pattern with 5/16-18 UNC-2B thread. Sold by Pro Gear and Transmission. Call us to confirm proper fit for your application.
Interchanges:
- 515632001
- 82350515632001
- F4HZ1104T
- GUHF770K
- TDA0515632001
- ZBRHF770K
- Automann 150S1101
- Automann 150S1105
- Gunite HF624K
- Gunite HF770K
- Webb 1521
- Webb 1528
- Webb 2523
Non returnable item
Features
FF/FG steer axle application, conventional hub-only configuration
GAWR: 14,600 lb, drum brake type
ABS tone ring included; ABS ring number 09-001940
ABS pilot diameters: 5.617/5.614 in. and 5.321/5.318 in.
10-bolt wheel stud and drum bolt pattern; 11.25 in. bolt circle diameter
Drum pilot diameter 8.778/8.775 in.; wheel pilot diameter 8.653/8.646 in.; flange outer diameter 13.00 in.
Hub cap bolt circle 4.50 in., 6-bolt pattern, 5/16-18 UNC-2B thread
Tech Specs
- Axle Application: Steer
- Axle Series: FF/FG
- Hub Style: Conventional
- Hub Type: Hub only
- Fully Dressed: No
- Brake Type: Drum
- GAWR: 14,600 lb
- Tone Ring: Yes
- ABS Ring Number: 09-001940
- ABS Pilot Diameter: 5.617/5.614 in.; 5.321/5.318 in.
- Wheel Stud Pattern: 10-bolt
- Wheel Stud Bolt Circle Diameter: 11.25 in.
- Wheel Stud Hole: 0.904/0.906 in.
- Drum Bolt Pattern: 10-bolt
- Drum Bolt Circle Diameter: 11.25 in.
- Drum Bolt Size: 0.904/0.906 in.
- Drum Pilot Diameter: 8.778/8.775 in.
- Wheel Pilot Diameter: 8.653/8.646 in.
- Flange Outer Diameter: 13.00 in.
- Hub Cap Bolt Circle Diameter: 4.50 in.
- Hub Cap Pattern: 6-bolt
- Hub Cap Bolt Thread: 5/16-18 UNC-2B
- Inner Bearing Surface (IBS) to Mounting Face: 5.19 in.
- IBS to Outer Bearing Surface (OBS): 3.395/3.355 in.
- IBS to Outer Surface: 4.455/4.415 in.
- Outer Cup: 3720
- Outer Cone: 3782
- Inner Cup: HM212011
- Inner Cone: HM212049
- Oil Seal: A1205B2264
- Base Part Number: 15632
- VMRS Code: 018-001-003
