Meritor part number 04-15712-002 or 0415712002 is a conventional rear drive axle hub assembly for L-series axle applications, rated at 17,850 lb GAWR. The hub is supplied without wheel studs and is designed for outboard drum brake configurations with a 10-bolt drum and a 10-bolt wheel stud pattern on a 10.826 in. bolt circle. Wheel pilot diameter runs 8.685 to 8.693 in., and the inner bearing surface to mounting face measures 3.193 to 3.252 in. Inner cone 47686, inner cup 47620, outer cup 39520, and outer cone 39590 are the specified bearing components. Drive flange has a 12-stud pattern on a 5.25 in. bolt circle. Call us to confirm proper fit for your application.
Interchanges:
- 12361075
- 415712002
- 82350415712002
- TDA0415712002
Features
L-series drive axle application, conventional hub style without wheel studs
17,850 lb GAWR rating
10-bolt drum brake pattern with outboard drum position, disc bolt circle 7.25 in.
10-bolt wheel stud pattern, 10.826 in. bolt circle, wheel pilot diameter 8.685-8.693 in.
Drive flange: 12-stud pattern, 5.25 in. bolt circle, 1/2-13 UNC-2B thread
Bearing set: inner cone 47686, inner cup 47620, outer cup 39520, outer cone 39590; oil seal A1205W1349
Tech Specs
- Axle Series: L
- Axle Application: Drive
- Hub Style: Conventional
- Hub Type: Hub only (without wheel studs)
- Fully Dressed: No
- GAWR: 17,850 lb
- Brake Type: Drum
- Drum Position: Outboard
- Drum Bolt Pattern: 10-bolt
- Disc Bolt Pattern: 10-bolt
- Disc Bolt Circle Diameter: 7.25 in.
- Disc Bolt Size: 9/16-12 UNC-2B
- Wheel Stud Pattern: 10-bolt
- Wheel Stud Bolt Circle Diameter: 10.826 in.
- Wheel Stud Hole: 0.796-0.798 in.
- Wheel Pilot Diameter: 8.685-8.693 in.
- IBS to Mounting Face: 3.193-3.252 in.
- IBS to Outer Surface: 7.287-7.327 in.
- IBS to OBS: 4.598-4.638 in.
- Flange Outer Diameter: 12.618 in.
- Drive Stud Pattern: 12-stud
- Drive Stud Bolt Circle Diameter: 5.25 in.
- Drive Stud Thread: 1/2-13 UNC-2B
- Drive Flange Stud Part Number: 08-205741
- Wheel Stud Part Number: 09-001811
- Inner Cone: 47686
- Inner Cup: 47620
- Outer Cup: 39520
- Outer Cone: 39590
- Oil Seal: A1205W1349
- Tone Ring: No
- Base Part Number: 15712
- VMRS Code: 018-002-001
