Features
Tone Ring:Y
Axle Series:FH
Hub Type:Hub only
Hub Style:Conventional
Axle Application:Steer
Fully Dressed:No
ABS Ring Number:09-002134
Base Part Number:15996
ABS Pilot Diameter:6.302/6.299 in.
Hub Cap Bolt Circle Diameter:6.00 in.
GAWR (lb):17600
Drum Bolt Size:.904/.906 in.
IBS to Outer Surface:4.13 in.
Wheel Stud Pattern:10
Drum Bolt Circle Diameter:13.189 in.
Inner Cone:6461A
Inner Cup:6420
Outer Cone:555S
Oil Seal:A1205P1108; A1205Z780
Outer Cup:552A
Inner Bearing Surface (IBS) to Mounting Face:4.13 in.
Wheel Stud Bolt Circle Diameter:13.189 in.
Hub Cap Pattern:06
Hub Cap Bolt Thread:3/8-16 UNC-2B
Wheel Stud Hole:.904/.906 in.
IBS to OBS:2.345/2.325 in.
Drum Bolt Pattern:10
Brake Type:Drum
VMRS Code:018-001-003
Drum Pilot Diameter:11.250/11.247 in.
Flange Outer Diameter:14.67/14.66 in.
Wheel Pilot Diameter:11.055/11.047 in.
Wheel Stud:09-002002
