Meritor drive axle shaft 3202C9129 is a genuine Meritor component for heavy-duty drive axle assemblies across multiple Meritor RD, RR, RS21, RS23, and RS26 series axle units. The shaft measures 43.07 inches in overall length with a 2.25-inch body diameter. The splined end carries 46 splines at 2.35 inches in spline diameter over a 9.14-inch spline length, straight-hole type with no lube or puller holes. The wheel-end flange measures 8.38 inches in diameter with an 8-bolt pattern on a 7.00-inch bolt circle, and 0.78-inch bolt holes. Call us to confirm proper fit for your axle assembly.
Interchanges:
- 1660760C1
- 3202C9129RI
- 3915026
- 82353202C9129
- ATI3202C9129
- HR3202C9129
- TDA3202C9129
Features
Genuine Meritor drive axle shaft, part number 3202C9129
46-spline end, 2.35 in. spline diameter, 9.14 in. spline length, straight hole type
Overall length: 43.07 in. | Body diameter: 2.25 in.
8-bolt wheel-end flange, 8.38 in. flange diameter, 7.00 in. bolt circle, 0.78 in. hole size
No lube holes, no puller holes
Tech Specs
- Bolt Circle Diameter: 7.00 in.
- Body Diameter: 2.25 in.
- Length: 43.07 in.
- Spline Count: 46
- Hole Size: 0.78 in.
- Spline Size: 2.35 in.
- Spline Length: 9.14 in.
- Hole Type: Straight
- Lube Holes: No
- Puller Holes: No
- Flange Diameter: 8.38 in.
- Hole Count: 8
