The Meritor R202003 Fastset no-ream king pin kit is listed for Meritor axle models FF981, MFS10, MFS12 and MFS13. The king pin is a double draw key type, 1.794 in. in diameter and 8.875 in. long, and the kit uses spiral no-ream bushings.
No-ream kits of this type use spiral bushings that seat in the steering knuckle without reaming afterward and can be fitted by hand rather than pressed in, which trims the labor and shop equipment a king pin job normally calls for. Grooves cut into the pin help carry grease to the joint's high-wear zones.
A genuine Meritor part from Pro Gear and Transmission. Call us to confirm proper fit for your axle.
Features
Fastset spiral no-ream bushings
Double draw key king pin, 1.794 in. diameter, 8.875 in. length
Bearing 1.822 in. inside diameter, 3.3455 in. outside diameter, 0.99 in. wide
Listed for Meritor axle models FF981, MFS10, MFS12 and MFS13
Bushings seat without reaming and go in by hand, no press needed
Tech Specs
- King pin type: Double draw key
- King pin diameter: 1.794 in.
- King pin length: 8.875 in.
- Bushing type: Spiral (no-ream)
- Bearing inside diameter: 1.822 in.
- Bearing outside diameter: 3.3455 in.
- Bearing width: 0.99 in.
- Axle make: Meritor
- Axle models: FF981, MFS10, MFS12, MFS13
