Meritor Rear Hub Assembly P/N: 04-15158-002 or 0415158002. This item is no longer available. We sell Genuine Meritor brake parts, brake calipers, brake chambers, brake dust shields, brake shoes, brake foot valves, and more. Genuine Meritor parts are just a click or call away.
Features
Axle Series:F
Tone Ring:N
Base Part Number:15158
IBS to Outer Surface:6.21/6.17 in.
Oil Seal:A1205W1557
Inner Cup:33462
Outer Cup:3920
Inner Bearing Surface (IBS) to Mounting Face:1.28 in.
IBS to OBS:3.74/3.70 in.
Outer Cone:3982
Wheel Stud Bolt Circle Diameter:10.827 in.
Wheel Stud Hole:.796/.798 in.
GAWR (lb):15000
Wheel Stud Pattern:08
Inner Cone:33287
Disc Bolt Pattern:05
Disc Bolt Circle Diameter:6.75 in.
Brake Type:Quadraulic
Disc Bolt Size:5/8-11 UNC-2B
Drive Stud Bolt Circle Dia:5.312 in.
Drive Stud Pattern:08
Drive Stud Thread:1/2-13 UNC-3B
Drive Flange Stud:08-205741
Flange Outer Diameter:12.62 in.
Wheel Pilot Diameter:8.69/8.693 in.
