Meritor hydraulic brake rotor 23-123460-002 or 23123460002 is a hat-style disc brake rotor with a 14.75 in. outside diameter. The rotor measures 3.81 in. deep with a 5.75 in. pilot diameter and a new disc thickness of 1.35 in., with a discard thickness of 1.23 in. It mounts on a 6-bolt pattern with a 7.25 in. bolt circle and 0.78 in. bolt holes, and includes 6 tapped holes for ABS mounting. Fits several medium duty vehicle sizes and name plates equipped with disc wheels. A genuine Meritor part from Pro Gear and Transmission. Call us to confirm proper fit for your application.
Interchanges:
- 23123460002RI
- 823523123460002
- ATI23123460002
- BW141274
- D6128
- HR23123460002
- RZ23123460002
- TDA23123460002
- Automann 153123460
- Bendix 141274
- Dayton-Walther 23123460
- Dayton-Walther 23123494
- FORD 86514074
Features
Hat-type hydraulic disc brake rotor, 14.75 in. outside diameter
Rotor depth 3.81 in., pilot diameter 5.75 in.
New disc thickness 1.35 in., discard thickness 1.23 in.
6-bolt mounting, 7.25 in. bolt circle, 0.78 in. bolt holes
6 tapped holes for ABS mounting
Fits several medium duty disc wheel applications; VMRS 013-017-001
Tech Specs
- Rotor type: Hat
- Outside diameter: 14.75 in.
- Rotor depth: 3.81 in.
- Pilot diameter: 5.75 in.
- New disc thickness: 1.35 in.
- Discard thickness: 1.23 in.
- Bolt hole number: 6
- Bolt circle diameter: 7.25 in.
- Bolt hole diameter: 0.78 in.
- ABS mounting: 6 tapped holes
- VMRS code: 013-017-001
