Genuine Midland Haldex Chamber brake parts P/N: SC16L, we offer the best service in the industry with years of expert knowledge! Call us if you have questions.
D = Dimension at Service Clampband
E = Stud Spacing: 4.75" (120.7mm) with 5/8-11 UNC studs
J = Pushrod Length from face of Service Housing: 5/8-18 UNF pushrod threads
K = Distance to Clevis Pin centerline from face of Service Housing
S1 = Service Clampband position (0°)
T = Air Port position (90°)
Features
Service Chamber - Long Stroke - Size T16
Steel Pressure Housing; Powder coated with resistance welded air ports
World Class Diaphragm; High quality rubber compound, resistant to heat and cold; Superior flexibility even at -40°F
Sturdy Service Housing; Powder coated for corrosion resistance; Step bottom with 12 gauge steel
Orange Alert® Stroke Indicator
Self-piloting Dust Shield
Air Port Threads 3/8-18 NPTF
Maximum Air Pressure: 150 psi
Tech Specs
- Actuator Type Size 16
- Stroke Type Long
- Available Stroke 2.50", 64mm
- A 4.2", 107mm
- D Dimension at Service Clampband
- 8.0"
- 203mm
- E 4.75", 120.7mm
- J 10.00"
- K Distance to Clevis Pin centerline from face of Service Housing
- T 90°
- S1 0°
- Weight 7.2 lbs. , 3.3 kg.
- Quantity 1
Additional Information
A = Length from mounting bracket to end of Spring HousingD = Dimension at Service Clampband
E = Stud Spacing: 4.75" (120.7mm) with 5/8-11 UNC studs
J = Pushrod Length from face of Service Housing: 5/8-18 UNF pushrod threads
K = Distance to Clevis Pin centerline from face of Service Housing
S1 = Service Clampband position (0°)
T = Air Port position (90°)
