The Midland Haldex KN68230 is a 12-volt, normally closed solenoid air valve designed for intermittent duty on heavy-duty truck air systems. It operates on a simple on-off electrical signal, delivering air through one port in the energized (on) position and closing flow when de-energized. Two 1/4" NPTF ports handle a standard operating pressure of 125 PSI, with a maximum rated pressure of 130 PSI. The unit draws 1 amp and grounds through its mounting bracket. It must be mounted upright per manufacturer specification. Available from Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
12-volt, normally closed solenoid air valve for intermittent use
Delivers air through one port in the energized (on) position; closes flow when off
Two 1/4" NPTF ports
Standard operating pressure: 125 PSI; maximum operating pressure: 130 PSI
Draws 1 amp; grounds through mounting bracket
Must be mounted in upright position per manufacturer specification
Tech Specs
- Ports (2) 1/4" NPTF
- Max Operating Pressure 130 PSI
- Standard Operating Pressure 125 PSI
