Genuine Midland Haldex T24/30 brake parts P/N: GC2430L, for more precise availability please give us a call and we will help you out!
B = Length of Piggyback
C = Dimension at rolled Spring Housing flange
D = Dimension at Service Clampband
E = Stud Spacing 4.75 in. (120.7mm)
J = Pushrod Length from face of Service Housing
K = Distance to Clevis Pin centerline from face of Service Housing
S1 = Service Clampband position (0°)
T = Air Port position (90°)
Replaces 2430021 and MA15425
Features
Combination - Long Stroke - Size 2430
Superior Power Spring Technology; Advanced powder coating process; Resists corrosion and fatigue
Double O-ring Centerseal; Two o-rings for positive sealing and plastic bearings for long life
World Class Diaphragm; High quality rubber compound, resistant to heat and cold; Superior flexibility even at -40°F
Rugged Service Housing; 9 gauge steel, powder coated
Orange Alert® Stroke Indicator
Self-piloting Dust Shield
Sizes to fit all drum brake applications
Tech Specs
- Stroke Type Long
- Available Stroke 2.50", 64mm
- A 9.3", 235mm
- B 6.8", 172mm
- C 8.3", 211mm
- D 9.4", 239mm
- J 10.00"
- Weight 19.1 lbs. , 8.7 kg.
- Quantity 1
Additional Information
A = Length from mounting bracket to end of Spring HousingB = Length of Piggyback
C = Dimension at rolled Spring Housing flange
D = Dimension at Service Clampband
E = Stud Spacing 4.75 in. (120.7mm)
J = Pushrod Length from face of Service Housing
K = Distance to Clevis Pin centerline from face of Service Housing
S1 = Service Clampband position (0°)
T = Air Port position (90°)
Replaces 2430021 and MA15425
